PM01-CPB PEELMASTER

01 / features

TWO 3-AXIS ROBOTS

single system to pick, place, and flip PCB panels, allowing an AAA/BBB workflow



MULTI-BATCH MODE

assignment of multiple jobs on a single rack possible



RECIPE FUNCTION

save selected settings as recipes for easy reuse at a later point in time

INTEGRATED CLEANER

external or internal cleaner for removal of unwanted particles

DOUBLE-SHEET DETECTION & SEPERATION

quick recognition and direct separation of double-sheet panels in magazine



EASY ACCESS

for maintenance to both CDTA650 and LDI, AOI or INKJET machine

CDTA650: COMPACT DESKTOP AUTOMATION

The CDTA650 is an all-in-one compact desktop automation. Its exceptionally small size is ideal for areas such as cleanrooms, where space is limited. The CDTA650 can function as a stand-alone solution and is compatible with most LDI, AOI and INKJET systems. It can be directly linked to a MES or ERP system, allowing for traceability and individual handling per PCB.

02 / specifications

FLOOR SPACE

1200 (flow dir.) x 1200mm



PRODUCTIVITY RATE

20 seconds/side



RACK SYSTEM

L-rack


POWER CONSUMPTION

1200 watts



PANEL SIZE

L300xW300 - L635xW635mm (extension available)



CLEANROOM SUITABLE

sterile operation

03 / CONNECTIVITY

SECS/GEM
